Cevotec’s carbon fiber tape for automated placement processes now commercially available

“With cevoTape we offer an alternative to expensive aeronautic-certified tapes”, specifies Thorsten Groene, Managing Director of Cevotec. “It is suited for non-aeronautic applications, e.g. the automotive industry. We’ve already received solid interest from manufacturers of AFP / ATL equipment who are looking for tape material for their customers. Initial tests of cevoTape with their robotic layup heads were performed successfully.”

Cevotec processes its own unidirectional carbon fiber tape (spread tow) in the SAMBA Series Fiber Patch Placement systems. But cevoTape is also perfectly matching the requirements of other automated fiber placement processes like AFP and ATL to create high quality laminates and can be used for a variety of different applications. cevoTape has a customized width within minimal tolerances and thanks to an integrated quality monitoring, it features a homogeneous filament distribution. The single-sided, uniformly distributed PA-Binder (Spunfab: PA1541, PA1300, further materials on request) is activated at temperatures from 90 to 160°C. Thus, cevoTape can be easily fixated during processing, and – another benefit – stored at room temperature.

“Customers may approach us with roving material of their choice and have us manufacture their individual tape”, says Michl. “We process any high-quality fiber.” Alternatively, there are pre-configured tapes using Tenax-E HTS45 fibers on stock, featuring 20 or 30 mm width and 80 – 107 gsm areal weight, separated with paper film, stored on Häfner spools (250 m, custom lengths on request).

Besides compatibility to the SAMBA Series manufacturing systems, Cevotec guarantees highest quality for all major placement processes as well as the dimensional tolerance of the tape that allows manufacturers to attain the high placement and operating precision they desire. “Such a tape quality achieves outstanding results in production processes and allows the economic application of AFP / ATL processes in non-aeronautic applications”, concludes Michl.
