Han® Configurator: Tailor-made interface design

There are two ways to work with the configurator:

• with selection support: input the number of contacts, voltage and current strength…and the configurator develops suggestions for suitable interfaces.
• without selection support: individuals familiar with the Han® portfolio have the option to construct the interface in the configurator on their own, e.g. select housing top/bottom, specify pin/socket inserts, etc.

Regardless of which option the user chooses, the Han^® configurator makes it easy to master the topic of "connectors" despite increasingly complex requirements and generally high product diversification. The most important aid is clarity, which is achieved by employing a 3D model to continuously visualise the state of the user’s component selection. In addition to the technical data that’s entered, the configurator factors in previous decisions. As a result, parts that don’t match with a previous selection are no longer displayed as an option – making it impossible to combine components incorrectly.

The new configurator also makes collaboration easier. Interface solutions which have been developed can be saved, shared and called up at any time. "The configurator enables a new kind of cooperation between manufacturer and supplier," says Andreas Wedel, Head of the Technical Competence Center at HARTING Electric.
