New laser line coatings provide Rabs <0,25% at the Design Wavelength
TECHSPEC® Fused Silica Wedge Prisms are specifically designed to provide high transmittance at the first through fourth Nd:YAG harmonics. New laser line coatings provide Rabs <0,25% at the design wavelength and offer guaranteed laser induced damage thresholds of 3 J/cm2 at 266 nm, 7,5 J/cm2 at 355 nm, 10 J/cm2 at 532 nm, and 15 J/cm2 and at 1064 nm, with a 20 ns pulse duration and 20 Hz pulse repetition rate.
Superior system performance with λ/10 surface flatness
Precision TECHSPEC® Fused Silica Wedge Prisms are optimized to ensure the highest level of system performance using tightly controlled specifications including λ/10 surface flatness, 20-10 surface quality, and a 15 arcsecond wedge tolerance. To alter a beam path, TECHSPEC® Fused Silica Wedge Prisms use one prism surface that is orthogonal to the optical axis and one wedged surface. When two Nd:YAG prisms with the same wedge deviation are used, this creates a risley prism pair, which allows for custom beam steering of up to two times the deviation. With diameter tolerances of +0,0/-0,1 mm, these laser line coated prisms are available in diameters of 12,5 mm and 25,0 mm with nominal deviations from 0,5° to 5,0°. TECHSPEC® Fused Silica Wedge Prisms are in-stock and available for immediate delivery.
Edmund Optics® (EO) is a leading global manufacturer and distributor of precision optics, optical assemblies and image processing components with headquarters in the USA and manufacturing facilities in the U.S., Asia and Europe and sales representatives around the globe. EO has the world’s largest inventory of optical components for immediate delivery and offers products, standard or customized, in small quantities but also in volume for various industries. Request a quote or place your order through the website www.edmundoptics.eu or contact us via phone +49 (0)6131 5700 0 or email email@example.com by reference to our catalogue.
