After participating in two 50MW projects in Kazakhstan before, Gantner will provide now its complete monitoring solution to the biggest solar farm in Central Asia, „Saran“, expanding its exposure in the country by another 100MW. For „Saran“ Gantner delivers Q.reader as data logger and Power plant controller, DC Combiner boxes, Meteo stations and Gantner.webportal as SCADA system.
Gantners monitoring and control solution "Made in Germany" is an optimised, individually tailored system and – as result of high quality engineering – based on newest technology.
The chosen components fulfil Gantners already in 1982 established approach to deliver reliable industry-leading solutions. All components have been carefully selected to comply with the extreme climate in the area. One challenge is the anticipated large ambient temperature range from -40 to 50°C as well as harsh winters with snow storms and ice.
Project scope and components provided by Gantner:
Q.reader data logger and Power plant controller
The heart of Gantners monitoring solution is the inverter independent datalogger Q.reader which tracks and controls all power plant information. The scalable modular design allows to control up to 100MW by one Q.reader. As Power plant controller (PPC) it provides all important functionality as absolute production constraint, power gradient constraint, voltage control, power factor control etc. The PPC fulfils the requirements of the Solar Energy Plants Grid Connection Code. Also grid communication is in the scope of our solution and based on IEC 60870 standard.
DC Combiner boxes
Gantners latest string level monitoring devices "string.bloxx" provide current measurements 10 times more accurate compared with competing monitoring solutions, not susceptible to temperature variance. Designed as an integral component of our individually customized DC Combiner boxes (DCB) "string.CB/CC" they are applicable for string voltage up to 1500V and dimensioned for up to 32 PV strings. The composition of our highly demanded DCBs has been ten of thousand times successfully proven itself in various solar projects, often with very special requirements in terms of both technical performance and of regional standards as well as in extreme climatic conditions.
Meteorological data such as solar irradiance, ambient temperature, module surface temperature and wind parameters are monitored according to IEC 61853 standard.
Commissioning of the power plant will be performed onsite by our engineers. Remote support is provided via high security connection with help of "gantner.RAS". Gantner.RAS is a remote access service for global fleet management of onsite DAQ devices.
Cloud based analysis software
Gantner.webportal is a cloud-based software solution for PV monitoring, data storage, visualization and analysis. Automated reporting and a dashboard provide traceability of the PV plant performance for the investor/owner. Forecasting for PV power production is based on semi-physical models that make use of PV system configuration information. Gantner.webportal is fully compliant with international standards as IEC 61724-2.
Gantner Instruments was founded in 1982. With offices in Germany, Austria, China, France, India and the US, and more than 3 GW of installed PV monitoring, Gantner Instruments is one of the biggest independent PV monitoring companies worldwide. The PV business unit, Gantner Instruments Environment Solutions, has established itself in the PV monitoring and control business with the highest level of product accuracy and reliability. The company has access to a global PV expert network and several collaborations with leading institutes. Furthermore, it has a worldwide presence with offices in both established and upcoming PV markets, and technical experts in many geographic areas on hand to deliver local service.
