The highly stable frame has a sophisticated cross beam arrangement for transporting heavy loads and for use in a very wide variety of road conditions, daily loading operations, and extreme conditions. The Kögel Cargo also has a low tare weight of 5,920 kilograms in the basic version and a highly robust body. This makes it ideally suited for payload-intensive transport. The Kögel Cargo is also equipped with the directionally stable and reliable KTA trailer axles as standard. The unique "double suspension" of the KTA, made from a soft rubber bearing and a spring steel wishbone, not only enhances the driving characteristics of the trailer but also reduces tyre wear.
Safety and load-securing
On the Kögel Cargo, no belts hang down in the loading area when the roof is open; they are integrated into the roof awning. This entirely eliminates straps snagging on the load. The new external frame profile greatly increases the accessibility of the VarioFix lashing points for optimum load-securing. 13 pairs of lashing shackles with an optional 4,000 kilograms of tensile force per lashing ring are also available. It goes without saying that the Cargo has the DIN EN 12642 Code XL load-securing certificate.
Heavy-duty RoRo equipment
For unaccompanied boat and ferry transport, the exhibit has optional RoRo equipment with a diagonal reinforcement from the side member to the front corners of the frame, a ten-millimetre-thick closed slide plate, a ten-millimetre-thick wheel plate, four pairs of heavy-duty lashing rings with a test force of 12,000 kilograms as well as signage in accordance with DIN EN 29367-2. Two vertical Delta rubber profiles on the front for protection of the air and lighting console, reinforced semi-trailer supports in a ferry design with rollers and an underride guard with skids shortened to 2,340 millimetres complete the heavy-duty RoRo equipment.
The Kögel Cargo is equipped with a Kögel trailer telematics module. The Basic telematics package collects data such as the real-time position, coupling status and the EBS data.
Wide variety of individual equipment
The Cargo on display at the Transport Compleet Gorinchem 2018 also shows a wide variety of individual features. These include, for example, a 12-millimetre-thick and 2,500-millimetre-high textured coated board on the inside of the front wall for increased front wall loading. A 720-millimetre long transition plate, made of steel chequer plate, is mounted above the rear end beam. The load-bearing capacity of the floor has been increased from a fork-lift axle load of 7.2 tonnes to eight tonnes by means of additional cross beams. Furthermore, the exhibit is equipped with reinforced steel rubber bumpers for increased collision protection. An eight-millimetre-thick lateral steel bracket across the entire width and locking cam protection mounted centrally on the end plate of the frame are fitted as forklift protection. The Kögel Cargo is fitted with the new Kögel EasyFix Stopper for quick and easy securing of the sliding roof when open. The Kögel EasyFix Stopper not only holds the sliding roof securely in position, but also allows you to close it easily after completing the loading process, without having to unlock it again. This system increases efficiency and safety during loading and unloading. Additional special equipment includes a toolbox, LED peripheral lights, LED reversing lights, tarpaulin cables with two mounts, a plank tarpaulin with vertical aluminium slats, and much more.
Cathodic dip-paint coating: lasting protection from corrosion
In the Kögel Cargo, the entire vehicle frame is given long-lasting protection from corrosion by nano ceramic and cathodic dip-paint coating, supplemented with UV painting.
Kögel is one of the leading trailer manufacturers in Europe. Since it was established in 1934, the company has manufactured more than 550,000 trailers. With its commercial vehicles and solutions for freight-forwarding companies and the construction industry, the company has been providing ‚Made in Germany‘ engineering quality for more than 80 years. During this period, it has maintained its passion for transport and innovation, enabling it to offer proven, long-lasting added value to freight-forwarding companies. The company headquarters and main production facility of Kögel Trailer GmbH & Co. KG are located in the Bavarian town of Burtenbach. Kögel also has factories and offices in Ulm (Germany), Duingen (Germany), Chocen (Czech Republic), Verona (Italy), Zwolle (Netherlands) and Moscow (Russia).
