The 4-day virtual training course for over 70 participants from different racing teams was very diverse: The first day started with the basics of the geometry and load capacity of gears – especially cylindrical gear pairs and planetary gear trains. Terms and principles were discussed that are essential for the calculation of gears. The attendees got the chance to use the web-based calculation software eAssistant, making it an ideal tool to form the basis for the following days of hands-on exercises.
By using the live chat function, the attendees were able to interact and to ask questions. On the second day of the workshop, the participants were given insights into the dimensioning and optimization of gears and took a deeper dive into the basics. Many tips and tricks and optimization strategies were shared during the workshop. Then the focus turned to the eAssistant 3D CAD plugins in order to create 3D models with just a few clicks. The third day of the seminar was devoted entirely to the SystemManager, a software extention for the configuration and calculation of entire systems of machine elements, e.g. multi-stage gearboxes, shift gear transmissions or different types of planetary gear trains.
From the first steps in dealing with the software to expert knowledge – the participants got an in-depth look at the basic
functions and how the software works. The SystemManager software offers many possibilities – from the fast and easy design and calculation of complete systems to the automatic meshing of housings and planet carriers. It gives the Formula Student Teams the ability to efficiently integrate the eAssistant SystemManager into their projects and to gain the full value of the software.
On the fourth and final day of the workshop, a Q&A session was held to answer all questions from participants and to clarify any subjects that were covered over the four days. That led to a rich discussion and a lively exchange among the participants. The last day ended with tons of new ideas and fresh input and most of all inspiration and drive for future projects.
GWJ Technology will continue to support the Formula Student Teams in 2021 – in whichever form possible. The answer to that remains to be seen. But with the success of the virtual workshop, GWJ Technology plans to keep including this format in the future.
Visit www.gwj.de for more information or contact GWJ at +49 (0) 5311293990 or send an email to info@gwj.de.
Focusing on mechanical engineering, GWJ Technology stands for high-quality products and professional software development for mechanical engineering to support engineers and designers in their daily work. The GWJ product range of innovative calculation software is wide – from standard software for classical machine elements with 3D CAD integration modules to the determination of whole systems up to a complex special software for 5-axis milling of gears. There are common features that all GWJ solutions share – intuitive design, sleek interface, easy to use and suitable applications for all users from beginner to very advanced. GWJ is constantly working on software enhancements and adding new features to the system in order to keep the applications up-to-date. Professional competence, state-of-the-art technology, a demand for high quality and excellent customer services are the key factors in GWJ´s business philosophy to give the customers the best possible service and advice to obtain new competitive advantages.
