Long-term security for existing investments
“Support for the PCI bus is essential for older CompactPCI system designs, yet some vendors are withdrawing from this market. The announcement that EKF Elektronik will continue to support the PCI bus for new CompactPCI designs therefore sends an important message to many users: They can safeguard their investment in this legacy technology for many more years, continue to upgrade their system designs with the latest processor technology, and reap all the benefits that come with it,” explains Manuel Murer, Business Development Manager at EKF Elektronik.
Advantages of such upgrades include higher energy efficiency, higher processor-integrated security and computing power, up-to-date software support, and above all support for artificial intelligence and the latest graphics features to provide the best possible user experience. As 11th Gen Intel Core and Xeon processors no longer support PCI natively, EKF Elektronik has installed a software-transparent PCIe-to-PCI bridge on the processor boards with CompactPCI Classic and CompactPCI PlusIO support. This allows developers to seamlessly port existing applications to the new boards.
New J2 for PlusIO
CompactPCI PlusIO users will find a new J2 connector on the new CompactPCI PlusIO (PICMG 2.30) boards, which is footprint-compatible with the CompactPCI Classic (PICMG 2.0) specification. This change was necessary because the J2 connector specifically developed for PlusIO has been discontinued. But there is no need to redesign the backplane. The only restriction is that high-speed backplane transfer is limited to 2.5 GT/s for PCIe Gen 1, and 1.5 Gbit/s for SATA. Depending on the application and system, it is possible to use the full bandwidth. The CompactPCI‘s PCI bus can be used in the usual bandwidth up to 133Mbyte/s.
The new CompactPCI processor boards with 11th Gen Intel Core processors in the CompactPCI Serial (SC9-TOCCATA) variant are expected to be available in mid-2023. The PC9-TOCCATA variants for CompactPCI Classic and CompactPCI PlusIO will go into series production later. Until that time, 7th generation PC7-FESTIVAL variants, which can be ordered now, provide a reliable long-term solution to existing availability problems for cPCI and PlusIO applications. All variants can be pre- ordered at sales@ekf.de.
Founded in 1972, EKF is one of the leading manufacturers of modular industrial micro computers today. For more than 40 years, extremely robust boards and systems in Eurocard format have been the company’s core competence. Based on CompactPCI Serial technology, the product portfolio today includes CPU boards with the latest Intel IIOT processor technology as well as a wide range of peripheral boards. Designed for applications in harsh environments, EKF products are also available in extended temperature range versions, including a protective coating.
The product range is rounded off by boxed CPU and networking solutions for IIOT applications, and mezzanine modules such as M.2 and XMC. The company also develops custom boards for individual customer needs daily. In-house SMT manufacturing guarantees highest quality as well as short lead times. EKF products come with a 3-year-warranty and guaranteed long-term availability. The ISO-9001 certification, effective since 1996, forms part of the company’s high quality concept.
